| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 2.3 GPM | 7.5 LPM |
| Max Head | 4.6 FT | 1 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 3/8"OD
Outlet: 3/8"OD
Material: Polypropylene (Front Housing, Rear Housing, Impeller), Buna N (O-Ring), Carbon/Teflon (Thrust Washer), 316 Stainless Steel (Shaft)
Submersible: Yes
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 3 GPM | 9 LPM |
| Max Head | 4.6 FT | 1 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 1/2"OD
Outlet: 1/2"OD
Material: Polypropylene (Front Housing, Rear Housing, Impeller), Buna N (O-Ring), Carbon/Teflon (Thrust Washer), 316 Stainless Steel (Shaft)
Submersible: Yes
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 5 GPM | 18.5 LPM |
| Max Head | 13 FT | 2.7 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 3/8"FPT & 3/4"MPT
Outlet: 1/4"MPT
Material: Polypropylene (Front and Rear Housing, Impeller), Viton (O-Ring), Stainless Steel (Shaft), Ceramic (Thrust Washer), Ceramic Magnet
Submersible: Yes
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 5 GPM | 18.5 LPM |
| Max Head | 13 FT | 2.7 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 3/8"FPT & 3/4"MPT
Outlet: 1/4"MPT
Material: Polypropylene (Front and Rear Housing, Impeller), Viton (O-Ring), 316 Stainless Steel (Shaft, Cooling Tube), Buna N (Cooling Tube Seal), Ceramic (Thrust Washer), Ceramic Magnet
Submersible: Yes
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 8.5 GPM | 31 LPM |
| Max Head | 19 FT | 4.3 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 3/4"FPT
Outlet: 1/2"MPT
Material: Polypropylene (Front and Rear Housing, Impeller), Cupric Nickel (Cooling Tube), Buna N (O-Ring, Cooling Tube Seal), Ceramic (Shaft, Thrust Washer), Ceramic Magnet
Submersible: Yes
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 14.5 GPM | 54.8 LPM |
| Max Head | 27 FT | 6 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 1"FPT
Outlet: 1/2"MPT
Material: Polypropylene (Front and Rear Housing, Impeller), Buna N (O-Ring), Ceramic (Shaft, Thrust Washers), Ceramic Magnet
Submersible: Yes
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 14.5 GPM | 54.8 LPM |
| Max Head | 27 FT | 6 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 1"FPT
Outlet: 1/2"MPT
Material: Polypropylene (Front and Rear Housing, Impeller), Buna N (O-Ring, Cooling Tube Seal), 316 Stainless Steel (Cooling Tube), Ceramic (Shaft, Thrust Washers), Ceramic Magnet
Submersible: Yes
| System | US | Metric |
|---|---|---|
| Max Flow | 2.7 GPM | 11 LPM |
| Max Head | 10.6 FT | 3.3 M |
Electrical/Air: 12V (Voltage Range 7-14)
Inlet: 3/8"FPT
Outlet: 3/8"OD
Material: Noryl (Front and Rear Housings), Nylon (Impeller), Carbon/Teflon (Thrust Washer), Buna N (O-Ring), 316 Stainless Steel (Shaft), Ceramic Magnet
Submersible: Yes
| System | US | Metric |
|---|---|---|
| Max Flow | 2.7 GPM | 11 LPM |
| Max Head | 10.6 FT | 3.3 M |
Electrical/Air: 24V (Voltage Range 12-28)
Inlet: 3/8"FPT
Outlet: 3/8"OD
Material: Noryl (Front and Rear Housings), Nylon (Impeller), Carbon/Teflon (Thrust Washer), Buna N (O-Ring), 316 Stainless Steel (Shaft), Ceramic Magnet
Submersible: Yes
| System | US | Metric |
|---|---|---|
| Max Flow | 2.7 GPM | 11 LPM |
| Max Head | 10.6 FT | 3.3 M |
Electrical/Air: 12V (Voltage Range 5.5-17.5)
Inlet: 3/8" FPT
Outlet: 3/8" OD
Material: Noryl (Front and Rear Housings), Polypropylene (Impeller), Carbon/Teflon (Thrust Washer), Buna N (O-Ring), 316 Stainless Steel (Shaft)
Submersible: Yes
| System | US | Metric |
|---|---|---|
| Max Flow | 2.7 GPM | 11 LPM |
| Max Head | 10.6 FT | 3.3 M |
Electrical/Air: 24V (Voltage Range 8.5-28)
Inlet: 3/8"FPT
Outlet: 3/8" OD
Material: Noryl (Front and Rear Housings), Polypropylene (Impeller), Carbon/Teflon (Thrust Washer), Buna N (O-Ring), 316 Stainless Steel (Shaft)
Submersible: Yes
