March Pump Series 8 are centrifugal magnetic drive pumps which have a maximum flow of 120GPM and a maximum head of 95 feet. They are available in Polypropylene, Kynar, and Stainless Steel. The inlet is 2 inch and the outlet is 1.5 inch. They use 3 and 5 horsepower three phase motors. Explosion proof motors for hazardous locations and 575V motors are additional options.
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 120 GPM | 400 LPM |
| Max Head | 95 FT | 20 M |
Electrical/Air: 1Ph 208-230V 60Hz or 3Ph 230/460V 60Hz & 380V 50Hz, or 3Ph 575V 60Hz
Inlet: 2"MPT
Outlet: 1-1/2"MPT
Material: Polypropylene (Front Housing, Impeller), Carbon Filled Polypropylene (Rear Housing), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Teflon/Ryton/Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 120 GPM | 400 LPM |
| Max Head | 95 FT | 20 M |
Electrical/Air: 1Ph 208-230V 60Hz or 3Ph 230/460V 60Hz & 380V 50Hz, or 3Ph 575V 60Hz
Inlet: 2"MPT
Outlet: 1-1/2"MPT
Material: Glass filled Kynar (Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 120 GPM | 400 LPM |
| Max Head | 90 FT | 19.3 M |
Electrical/Air: 1Ph 208-230V 60Hz or 3Ph 230/460V 60Hz & 380V 50Hz, or 3Ph 575V 60Hz
Inlet: 2"MPT
Outlet: 1-1/2"MPT
Material: 316 Stainless Steel (Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers) Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 80 GPM | 246 LPM |
| Max Head | 86 FT | 17 M |
Electrical/Air: 1Ph 208-230V 60Hz or 3Ph 230/460V 60Hz & 380V 50Hz, or 3Ph 575V 60Hz
Inlet: 1-1/2"MPT
Outlet: 1-1/2"MPT
Material: Polypropylene (Housings, Impeller, Drain Plug), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing), Teflon (Fill Plug)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 150 GPM | 470 LPM |
| Max Head | 95 FT | 20 M |
Electrical/Air: 3Ph 230/460V 60Hz & 380V 50Hz, or 3Ph 575V 60Hz
Inlet: 2"MPT
Outlet: 1-1/2"MPT
Material: Polypropylene (Front Housing, Impeller), Carbon Filled Polypropylene (Rear Housing), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Teflon/Ryton/Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 150 GPM | 470 LPM |
| Max Head | 95 FT | 20 M |
Electrical/Air: 3Ph 230/460V 60Hz & 380V 50Hz, or 3Ph 575V 60Hz
Inlet: 2"MPT
Outlet: 1-1/2"MPT
Material: Glass filled Kynar (Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing)
| System | US | Metric |
|---|---|---|
| Max Flow | 97 GPM | 367 LPM |
| Max Head | 63 FT | 19.2 M |
Electrical/Air: 65PSI and 125CFM
Inlet: 2"MPT
Outlet: 1-1/2"MPT
Material: (Front Housing, Impeller), Carbon Filled Polypropylene (Rear Housing), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Teflon/Ryton/Carbon (Bushing)
| System | US | Metric |
|---|---|---|
| Max Flow | 97 GPM | 367 LPM |
| Max Head | 63 FT | 19.2 M |
Electrical/Air: 65PSI and 125CFM
Inlet: 2"MPT
Outlet: 1-1/2"MPT
Material: Glass filled Kynar (Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing)
| System | US | Metric |
|---|---|---|
| Max Flow | 97 GPM | 367 LPM |
| Max Head | 63 FT | 19.2 M |
Electrical/Air: 65PSI and 125CFM
Inlet: 2"MPT
Outlet: 1-1/2"MPT
Material: 316 Stainless Steel (Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers) Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 120 GPM | 400 LPM |
| Max Head | 95 FT | 20 M |
Electrical/Air: 3Ph 230/460V 60Hz & 380V 50Hz
Inlet: 2" ANSI Class 150 Flange
Outlet: 1-1/2" ANSI Class 150 Flange
Material: Polypropylene (Front Housing, Impeller), Carbon Filled Polypropylene (Rear Housing), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Teflon/Ryton/Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 120 GPM | 400 LPM |
| Max Head | 95 FT | 20 M |
Electrical/Air: 3Ph 230/460V 60Hz & 380V 50Hz
Inlet: 2" ANSI Class 150 Flange
Outlet: 1-1/2" ANSI Class 150 Flange
Material: Glass Filled Kynar(Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 120 GPM | 400 LPM |
| Max Head | 90 FT | 19.3 M |
Electrical/Air: 1Ph 208/230V 60Hz or 3Ph 230/460V 60Hz & 380V 50Hz, or 3Ph 575V 60Hz
Inlet: 2" ANSI Class 150 Flange
Outlet: 1-1/2" ANSI Class 150 Flange
Material: 316 Stainless Steel (Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers) Carbon (Bushing)
