| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 7 GPM | 26.5 LPM |
| Max Head | 18.6 FT | 5.7 M |
Electrical/Air: 115V 50/60Hz
Inlet: 1/2"MPT
Outlet: 1/2"MPT
Material: Polysulfone (Front Housing), Stainless Steel (Rear Housing and Shaft), Teflon (Thrust Washer), Silicone (O-Ring), Ryton/Teflon/Glass (Impeller)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 8 GPM | 30.3 LPM |
| Max Head | 18.6 FT | 5.7 M |
Electrical/Air: 115V 50/60Hz
Inlet: 3/8"FPT and 3/4"MPT
Outlet: 1/2"MPT
Material: Polysulfone (Front Housing), Stainless Steel (Rear Housing and Shaft), Teflon (Thrust Washer), Silicone (O-Ring), Ryton/Teflon/Glass (Impeller)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 7 GPM | 26.5 LPM |
| Max Head | 18.6 FT | 5.7 M |
Electrical/Air: 115V 50/60Hz
Inlet: 1/2"MPT
Outlet: 1/2"MPT
Material: Stainless Steel (Front and Rear Housing, Shaft), Teflon (Thrust Washer), Silicone (O-Ring), Ryton/Teflon/Glass (Impeller)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 8 GPM | 30.3 LPM |
| Max Head | 18.6 FT | 5.7 M |
Electrical/Air: 115V 50/60Hz
Inlet: 3/4"MPT
Outlet: 1/2"MPT
Material: Stainless Steel (Front and Rear Housing, Shaft), Teflon (Thrust Washer), Silicone (O-Ring), Ryton/Teflon/Glass (Impeller)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 17 GPM | 64.4 LPM |
| Max Head | 27 FT | 8.2 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 1"FPT
Outlet: 1/2"MPT
Material: Polysulfone (Front and Rear Housing, Impeller), Stainless Steel (Magnet Shell, Shaft), Buna N (O-Ring), Ceramic (Thrust Washers)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 17 GPM | 64.4 LPM |
| Max Head | 27 FT | 8.2 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 1"FPT
Outlet: 1/2"MPT
Material: Polysulfone (Impeller), 316 Stainless Steel (Front and Rear Housing, Magnet Shell, Shaft), Buna N (O-Ring), Ceramic (Thrust Washers), Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 18 GPM | 60 LPM |
| Max Head | 29 FT | 8.9 M |
Electrical/Air: 1Ph 115/230V 60Hz, 1Ph 110/220V 50Hz
Inlet: 1"FPT
Outlet: 1/2"MPT
Material: Polysulfone (Impeller), 316 Stainless Steel (Front and Rear Housing, Magnet Shell, Shaft), Buna N (O-Ring), Ceramic (Thrust Washers), Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 53 GPM | 180 LPM |
| Max Head | 57.5 FT | 12.3 M |
Electrical/Air: 1Ph 115/208/230V 60Hz &115/230V 50Hz or 3Ph 208/230/460V 60Hz & 190/380V 50Hz, or 3Ph 575V 60Hz
Inlet: 1.5" Tri Clamp
Outlet: 1.5" Tri Clamp
Material: 316 Stainless Steel (Front Housing, Rear Housing, Shaft), Glass Filled Kynar (Impeller), EPDM (O-Ring), Ceramic (Thrust Washers), Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 120 GPM | 400 LPM |
| Max Head | 90 FT | 19.3 M |
Electrical/Air: 3Ph 208/230/460V 60Hz & 190/380V 50Hz
Inlet: 2" Sanitary Flange
Outlet: 1.5" Sanitary Flanges
Material: 316 Stainless Steel (Front and Rear Housing), Glass Filled Kynar (Impeller) Viton (O-Ring), Ceramic (Shaft, Thrust Washers) Carbon (Bushing)
