| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 14 GPM | 50 LPM |
| Max Head | 21.5 FT | 4.7 M |
Electrical/Air: 115V 50/60Hz or 230V 50/60Hz
Inlet: 1"MPT (Self Priming Chamber)
Outlet: 1/2"MPT (Pump Outlet
Material: Polypropylene (Front and Rear Housing, Impeller), Ceramic (Shaft, Thrust Washers), Viton (O-Ring), High Density Polyethylene (750 Self Priming Chamber)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 18 GPM | 60.5 LPM |
| Max Head | 29 FT | 6.3 M |
Electrical/Air: 1Ph 115/230V 60Hz, 1Ph 110/220V 50Hz, or 3Ph 230/460V 50/60Hz, or 3Ph 575V 60Hz
Inlet: 1"MPT (750 Self Priming Chamber)
Outlet: 1/2"MPT (Pump Outlet)
Material: Polypropylene (Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), High Density Polyethylene (Self Priming Chamber)
| System | US | Metric |
|---|---|---|
| Max Flow | 18 GPM | 68 LPM |
| Max Head | 50 FT | 15.2 M |
Electrical/Air: 60PSI and 7CFM
Inlet: 1"MPT (750 Self Priming Chamber)
Outlet: 1/2"MPT
Material: Polypropylene (Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 18 GPM | 60.5 LPM |
| Max Head | 29 FT | 6.3 M |
Electrical/Air: 1Ph 115/230V 60Hz, 1Ph 110/220V 50Hz, or 3Ph 230/460V 50/60Hz, or 3Ph 575V 60Hz
Inlet: 1"MPT (750 Self Priming Chamber)
Outlet: 1/2"MPT (Pump Outlet)
Material: Glass Filled Kynar (Front and Rear Housing, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), High Density Polyethylene (Self Priming Chamber)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 53 GPM | 180 LPM |
| Max Head | 52 FT | 11 M |
Electrical/Air: 1Ph 115/208/230V 60Hz & 110/220V 50Hz or 3Ph 230/460V 50/60Hz, or 3Ph 575V 60Hz
Inlet: 1-1/2"MPT
Outlet: 1"MPT
Material: Polypropylene (Housings, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 53 GPM | 180 LPM |
| Max Head | 52 FT | 11 M |
Electrical/Air: 1Ph 115/208/230V 60Hz & 110/220V 50Hz or 3Ph 230/460V 50/60Hz, or 3Ph 575V 60Hz
Inlet: 1-1/2"MPT
Outlet: 1"MPT
Material: Glass Filled Kynar (Impeller, Housings), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing)
| System | US | Metric |
|---|---|---|
| Max Flow | 40 GPM | 151 LPM |
| Max Head | 65 FT | 19.8 M |
Electrical/Air: 95PSI and 30 CFM
Inlet: 1-1/2"MPT
Outlet: 1"MPT
Material: Polypropylene (Housings, Impeller), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing)
| System | US | Metric |
|---|---|---|
| Max Flow | 40 GPM | 151 LPM |
| Max Head | 65 FT | 19.8 M |
Electrical/Air: 95PSI and 30 CFM
Inlet: 1-1/2"MPT
Outlet: 1"MPT
Material: Glass Filled Kynar (Impeller, Housings), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing)
| Unit System | 60Hz | 50Hz |
|---|---|---|
| Max Flow | 80 GPM | 246 LPM |
| Max Head | 86 FT | 17 M |
Electrical/Air: 1Ph 208-230V 60Hz or 3Ph 230/460V 60Hz & 380V 50Hz, or 3Ph 575V 60Hz
Inlet: 1-1/2"MPT
Outlet: 1-1/2"MPT
Material: Polypropylene (Housings, Impeller, Drain Plug), Viton (O-Ring), Ceramic (Shaft, Thrust Washers), Carbon (Bushing), Teflon (Fill Plug)
