BC-2CP-MD 24V DC Brushless Mag Drive Pump

Perfect for Applications Including

Applications for the BC-2CP-MD Brushless Mag Drive Pump includes chemical recirculation, chemical transfer, computer cooling, and x ray machine cooling.

Great for Chemicals Including

The BC-2CP-MD Brushless has pumped Acetic Acid, Citric Acid, Ethylene Glycol, Formaldehyde, Hydrochloric Acid (Muriatic), Nitric Acid, Phosphoric Acid, Potassium Chloride, Potassium Hydroxide, Sodium Hydroxide (Caustic Soda), Sodium Chloride, Sulfuric Acid, Fresh Water, Salt Water, DI Water, and many more chemicals.  The BC-2CP-MD Brushless may have been modified to handle these chemicals.  This pump may have to be modified to pump specific gravities, viscosities, or elevated temperatures different then ambient water.  Please contact March Pump to review your application before using the BC-2CP-MD Brushless. Chemical Resistance Chart

Summary Paragraph

March Pump’s industrial BC-2CP-MD Brushless is an American seal-less centrifugal magnetic drive pump ideal for applications such as chemical recirculation, chemical transfer, and solar equipment. It is capable of generating a maximum flow of 6 gallons per minute at 2 feet, and its maximum head is 29 Feet (12.5PSI). The standard wet end (the materials that come into contact with the solution) is composed of Polypropylene, Viton, and Ceramic. The inlet connection is 3/8 female pipe thread and 3/4 male pipe thread, and the outlet is 1/4 inch male pipe thread. The standard motor is a 0.04 24V Horsepower DC Brushless Motor.  The 24 Volt Motor has an operating range from 14 to 30 Volts.  The maximum internal pressure the pump can tolerate is 50PSI, and the maximum liquid temperature is 190 Fahrenheit or 87 Celsius. The March BC-2CP-MD Brushless centrifugal magnetic drive pump is capable of handling mildly or highly corrosive chemicals, acids, and solvents. To determine if the March BC-2CP-MD Brushless  is suitable for your application, please contact March Pump.
