1U-MD Mag Drive Pump

Perfect for Applications Including

Applications for the 1U-MD Magnetic Drive Pump include chemical transfer, photographic processing equipment, refrigeration systems, and water displays.

Great for Chemicals Including

The 1U-MD has pumped Acetone, Ammonium Chloride, Ammonium Chloride, Ammonium Hydroxide, Citric Acid, Ethylene Glycol, Magnesium Nitrate, Potassium Carbonate, Sodium Borate, Fresh Water, Salt Water, and many more chemicals.  The 1U-MD may have been modified to handle these chemicals.  This pump may have to be modified to pump specific gravities, viscosities, or elevated temperatures different then ambient water.  Please contact March Pump to review your application before using the 1U-MD. Chemical Resistance Chart

Summary Paragraph

March Pump’s industrial 1U-MD is an American submersible seal-less centrifugal magnetic drive pump. It is capable of generating a maximum flow of 2.3 gallons per minute at 0.25 feet, and its maximum head is 4.5 Feet (2PSI).  The 1U-MD pump must be used submerged. The standard wet end (the materials that come into contact with the solution) is composed of Polypropylene, Buna N, Carbon/Teflon, Stainless Steel, and Delrin.  When submerged, Epoxy, Noryl, and the SJT Cord are also in contact with the solution. The inlet connection is a screen, and the outlet is 1/4 inch male pipe thread. The standard motor is a 1 Phase 115V or 230V 0.005 Horsepower motor, which can be run on either 50 or 60 hertz (there are performance differences between the hertz options).  The maximum internal pressure the pump can tolerate is 50PSI, and the maximum liquid temperature is 190 Fahrenheit or 160 Celsius in open air, or 87 Fahrenheit or 71 Celsius if submerged. The March 1U-MD centrifugal magnetic drive pump is capable of handling fresh water, salt water, and mild chemicals. To determine if the March 1U-MD is suitable for your application, please contact March Pump.
