Unit System | 60Hz | 50Hz |
---|---|---|
Max Flow | 22 GPM | 70 LPM |
Max Head | 87 FT | 18.5 M |
Electrical/Air: 1Ph 115/208/230V 60Hz, 110/220V 50Hz or 3Ph 208/230/460V 60Hz, 190/380V 50Hz
Inlet: 1"Female BSPP (Adapter with 1" MPT available)
Outlet: 1/2"Male BSPP (Adapter with 1/2" FPT available)
Material: Polypropylene (Front Housing, Stage Housings, Rear Housings, Impeller), Viton (O-Ring), Ceramic (Thurst Washers, Shaft)
Unit System | 60Hz | 50Hz |
---|---|---|
Max Flow | 10.5 GPM | 81 LPM |
Max Head | 96 FT | 23.1 M |
Electrical/Air: 1Ph 115-208/230V 60Hz, 110/220V Hz, or 3Ph 208-230/460V 60Hz, 190/380V 50Hz
Inlet: 1"Female BSPP (Adapter with 1"MPT available)
Outlet: 1/2"MPT for 60Hz Pumps with Restrictor, 1/2" Male BSPP for 50Hz Pumps without Restrictor
Material: Ryton (Front Housing, Stage Housings, Rear Housings, Impeller), Viton (O-Ring), Ceramic (Thrust Washers), 316 Stainless Steel (Shaft)
